Código: C-10
Marca: Caterpillar
| Especificação, Motor Caterpillar C-10 Industrial, 354 HP Test Specification Data |
||||||
| Description | Nominal | Ceiling | Floor | |||
| Corr Full Load Power | 365 HP | 376 HP | 354 HP | |||
| Full Load Speed | 2100 RPM | 2110 RPM | 2090 RPM | |||
| High Idle Speed | 2120 RPM | 2130 RPM | 2110 RPM | |||
| Low Idle Speed | 700 RPM | 710 RPM | 690 RPM | |||
| Governor Setting Speed | 0 RPM | 0 RPM | 0 RPM | |||
| FL Static Fuel Setting | 0.425 IN | |||||
| FT Static Fuel Setting | 0.394 IN | |||||
| FLS (Intercept) | -5 | |||||
| FTS (Slope) | 6 | |||||
| Adjusted Boost | 27.0 PSI | 31.0 PSI | 22.9 PSI | |||
| Adj Boost at TC RPM | 25.5 PSI | 29.4 PSI | 21.7 PSI | |||
| Power Loss/cyl | 26.8% C FL PWR | 34.9% C FL PWR | 13.4% C FL PWR | |||
| Inlet Fuel Pressure | 3 PSI | 0 PSI | ||||
| Inlet Fuel Temp | 86 DEG F | 95 DEG F | 77 DEG F | |||
| Fuel Pressure | 95 PSI | 119 PSI | 66 PSI | |||
| Fuel Density | 36 DEG API | 34 DEG API | ||||
| Boost Constant | 1 | |||||
| Governor Setting Constant | 0 | |||||
| Gov Setting Torq | 0% RTD TRQ | 0% RTD TRQ | 0% RTD TRQ | |||
| Corrected Fuel Rate | 18.5 GAL/HR | 19.4 GAL/HR | 17.6 GAL/HR | |||
| CSFC | 0.357 LB/HP-HR | 0.375 LB/HP-HR | 0.337 LB/HP-HR | |||
| Torque Check Speed | 1400 RPM | 1410 RPM | 1390 RPM | |||
| Corr Torq Rise AT TC RPM | 27.7% | 0% | 0% | |||
| Corr Torq AT TC RPM | 1165 LB/FT | 1247 LB/FT | 1083 LB/FT | |||
| C Fuel Rate At TC RPM | 15.4 GAL/HR | 16.2 GAL/HR | 14.6 GAL/HR | |||
| CSFC AT TC RPM | 0.350 LB/HP-HR | 0.368 LB/HP-HR | 0.331 LB/HP-HR | |||
| Temp Jacket Water Pump Inlet | 192 DEG F | 198 DEG F | 187 DEG F | |||
| Delta T Jacket Water(Out-In) | 11 DEG F | 20 DEG F | 2 DEG F | |||
| Temp Engine Water Outlet | 98 | 101 | 95 | |||
| Inlet Manifold Temp | 109 DEG F | 133 DEG F | 108 DEG F | |||
| Water Temp To SCAC | 32 DEG F | 32 DEG F | 32 DEG F | |||
| SCAC Water Flow | 0 GAL/min | 0 GAL/min | 0 GAL/min | |||
| Oil Pressure | 52.6 PSI | 87.0 PSI | 36.3 PSI | |||
| Oil Pressure Low Idle | 19.7 PSI | 87.0 PSI | 10.9 PSI | |||
| Inlet Air Pressure | 15 PSI | 13 PSI | ||||
| Inlet Air Restriction | 0.00 PSI | 0.00 PSI | ||||
| Inlet Air Temperature | 122 DEG F | 50 DEG F | ||||
